Product Details

Aran’s High Performance Safety Valves • Are designed to meet all industrial applications. • Open rapidly with an over pressure of 5 % to the full design lift. • Are used particularly for vapour and gases where the maximum mass flow has to be discharged rapidly. • Have a maximum blow down of minus 10 % for steam/gas service and minus 20 % for liquid service. • Are one of the best selling spring loaded safety valve worldwide. • Are developed in a close cooperation with plant engineers and service specialists. • Serve for protection of processes and equipment. • Are approved by all important approval organizations worldwide which ensures the worldwide applicability.

Specification:

Nominal Size:1”~8”(DN25~DN200)

Pressure Rating:150LB~2500LB (PN10~PN420)

Body Material: WCB, LCB, CF8M, CF3M,WC6,WC9 (1.0619, 1.4408, 1.7357)

Design Standard: API 526

Flange End Standard: EN1092, ASME B16.5

Temperature Standard: ASME
